Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Zhuzhou Mingri Cemented Carbide Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

  • 1
  • 2
  • 3

Brand Name : Rixin

Model Number : customized

Certification : ISO9001:2008

Place of Origin : Zhuzhou Hunan Province

MOQ : 10

Price : USD + 32~65 + KG

Supply Ability : 50 Tons / month

Delivery Time : 7-21 working days

Packaging Details : in inner box ,then into carton

Product name : tungsten carbide scraper blade

Keyword : carbide scraper blade

Material : Tungsten carbdie raw material

Surface treatment : Sand Blasting

grade : MR12UF

T.R.S : 4500 N/MM2

Hardness : 92 HRA

Density : 14.15 g/cm3

Contact Now

tungsten carbide scraper blade/ carbide tip tool parts

Grade,properties & application of carbide scraper blade


Grade Properties
T.R.S(M/mm2) Hardness(HRA) Density(g/cm3)
MR10AF 4000 92 14.4
MR12UF 4500 92 14.15
F20 3500 91.5 14.65
Other grades can be offered as per customers' requirement

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Application of carbide scraper blade


1, carbide scraper blade brazed on steel body to clean conveyor belt which is in mining dustry

2, carbide scraper blade brazed on steel body to clean conveyor belt which is in agriculture

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

production process of carbide scraper blade


1. The manufacturing process begins with the composition of a specific tungsten carbide powder mixture- tailored for the application.
2. This powder is compacted into a form.
3. In a high- temperature sintering furnace, the tungsten carbide structure of the blank is shaped at precise temperatures for strictly defined periods.
4. During this heat treatment, the tungsten carbide blank undergoes shrinkage of some 50% in volume.
5. The sintered tungsten carbide component gains its final finish by additional grinding, lapping and/ or polishing processes

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Packing and delivery of carbide scraper blade


Generally we will take care of your machine packages well like picture show.

Firstly our worker will make sure your carbide scraper blade clean before package.

Then add plastci foam into inner box for the whole carbide scraper blade for sweet protection.

At last we will make export standard strong cartonn or plywood case package according to your needs.

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

company information


Zhuzhou Mingri Tungsten Carbide Co., Ltd. was established in May of 2001 with the investment of RMB 40 million. We have up-to-date production machine line and a lot of technicians.

Zhuzhou MingRi Cemented carbide co.,ltd is located in the tungsten carbide hometown , convenient transportation, from changsha airport just 40 minutes, wuhan just 1.5 hour, from guangzhou just 2 hours. A favorable peripheral environment for cemented carbide manufacturing provides a natural barrier. Convenient traffic for tomorrow's internationalization laid a wide road.

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners

Why choose us


1. We joined Alibaba Trade Assurance to make sure the buyer’s benefit. If can’t meet the details in the contract, 100% of your payment will be returned.


2. As a professional manufacturer, we have 18 years factory experience for carbide scraper tips. We are devoting to the research and manufacturing of many different type and size.


3. You can see from the below picture that many customers visited our exhibition booth, more and more customers in the world are using our carbide scraper tips , we received many good feedbacks or reviews from lots of countries.

Tungsten Carbide Scraper Blade / Carbide Tip Tool Parts For Conveyor Cleaners
